■Optical Material Additives
Infrared Absorbers
JADEWIN IRA OYP 01
JADEWIN IRA SYP 02
JADEWIN IRA HSYP 03
■Optical Material Additives
JADEWIN Infrared Absorbers
IRA OYP 01 IRA SYP 02 IRA HSYP 03
JADEWIN Infrared Absorbers are mainly used in transparent conductive coating, Antistatic Coating and also radiation protection coating.
JADEWIN Infrared Absorbers can also be used in electrode material ,eg. transparency electrode,Cathode material of lithium cell, Thermal insulation material , Infrared absorbing or reflective material.
The end application includes LED Screen,Flat Panel Display（FPD）,Plasma display(PDP),Touch Screen, electroluminescent(EL) materials, Cold light board, LED, LCD, OLED, Membrane Switch, Epoxy , Optical Lens, Security Ink and also automobile film.
JADEWIN IRA OYP01
| Appearance | Yellow green powder |
| Specific surface area （m2/g） | 30-50 |
| Powder resistance（Ω.cm2） | 15-25 |
| Particle（nm） | 10-100 |
Cold light board,LED, LCD, OLED, Membrane Switch, Epoxy , Optical Lens, Security Ink and also automobile film.
JADEWIN IRA SYP02
| Appearance | Light Green Powder |
| Specific surface area （m2/g） | 30-50 |
| Powder resistance（Ω.cm2） | 5-10 |
| Particle（nm） | 5-10 |
Solar film , Anti-Static Coatings
JADEWIN IRA HSYP 03
| Appearance | Light Green Powder |
| Specific surface area （m2/g） | 30-50 |
| Powder resistance（Ω.cm2） | 5-10 |
| Particle（nm） | 5-10 |
Automobile Thermal Insulation Glass,PVB,PET,Thermal Insulation Film,Electronic Products
JADEWIN IRA CD 04
| Appearance | Dark Brown Powder |
| Absorption（λmax/nm） | 1080-1090 |
| Melting Point(DC) | 279-289 |
| Water（%） | 0.6Max |
Infrared Dyes
JADEWIN IRA CD 05
| Appearance | Dark Green Powder |
| Absorption（λmax/nm） | 895-905 |
| Melting Point(DC) | 245-289 |
| Water（%） | 0.6Max |
Infrared Dyes
JADEWIN IRA CD 06
| Appearance | Dark Powder |
| Absorption（λmax/nm） | 835-845 |
| Melting Point(DC) | 249-288 |
| Water（%） | 0.6Max |
Infrared Dyes
